QuickTake® 30 Pump (10 to 30 L/min)
Designed for use with BioStage viable cascade impactor, VersaTrap spore trap cassettes, asbestos filters, or impactors. Includes keypad programmable timer, display of sample time, and end-of-cycle alarms. Accessories include mounting bracket for viable cascade impactors, sampling wand for spore trap samples in ductwork, and tripod stand.

  • 10 to 30 L/min constant flow sample pump
    - Maintains set flow throughout a sampling period for complete sample integrity
    - Ideal for use with BioStage viable cascade impactors, spore trap cassettes such as the VersaTrap, microvacuum cassettes, or other samplers that require flows to 30 L/min
  • Long run times on one Li-Ion battery charge
    - AC charger/adapter for extended sampling
    - Rechargeable lithium-ion battery pack
  • Easy to use programmable timer for unattended sampling
    - Select sample time presets or customize timer from 1 to 999 minutes
    - Continuous run with manual shut-off
    - Intermittent sampling
    - Large, easy-to-use keypad
  • Compact and portable
    - 9.3 x 8.4 x 3.5 inches (23.6 x 21.3 x 8.9 cm)
    - Weighs only 4.8 pounds (2.2 kg)
    - Handle for easy portability
  • Versatile sampling accessories
    - Wand for sampling in ductwork and other hard-to-reach areas
    - Optional mounting bracket for viable impactor
  • Easy to use
    - Large keypad control
    - End-of-cycle visual and audible alarms
    - Handy front-mounted intake for fast and simple media setup
  • High-contrast digital display

Specifications

Flow Range
10 to 30 L/min
Flow Compensation Accuracy
± 5% of set flow
Compensating Flow Back Pressure Range

10 L/min at 90 inches water back pressure
20 L/min at 50 inches water back pressure
30 L/min at 15 inches water back pressure
Typical Back Pressure of Sampling Media (inches water)
Flow Rate
10.0
12.0
15.0
20.0
Filter/Pore Size (µm)

25-mm MCE/0.8
65
80
103
148
25-mm MCE/0.45
138
172
> 200
37-mm MCE/0.8
22
28
36
51
37-mm PVC/5.0
9
11
15
21
Compare the information in this table to compensation range to determine appropriate applications.
Power
Rechargeable 7.4-volt, 9.6-Ah capacity, 71.04 Wh lithium-ion (Li-Ion) battery or battery with AC charger/adapter (100-240 V)
Battery Recharge Time
Approximately 5 hrs with approved charger
Typical Cumulative Run Time

Spore Trap (VersaTrap): 5 hrs at 15 L/min (battery only)
BioStage viable cascade impactor: 4 hrs at 28.3 L/min (battery only)
25-mm, 1.2-µm MCE filter: For maximum air volumes during asbestos clearance sampling, use QuickTake 30 with a 25-mm, 1.2-µm MCE filter at 10 L/min with fully charged battery and AC charger/adapter to achieve 9+ hrs of run time, a total air volume of 5400 L
37-mm, 0.8-µm MCE filter: 14 hrs at 10 L/min (battery only)

Note: The AC charger/adapter can be used to extend battery run time, but it is not a battery eliminator. Therefore, it will not provide indefinite run times.

Temperature
Operating: 32 to 113 F (0 to 45 C)
Storage: -4 to 95 F (-20 to 35 C)
Charging: 32 to 113 F (0 to 45 C)
Run Time Features
User-selectable features, user-adjustable presets. See Operating Instructions.
Preset timed runs: 1, 2, 5, 10, or 15 min
Manually set continuous run with manual shut-off: 1 to 999 min (repeats 1 to 999-min runs indefinitely until user stops pump or power supply is depleted)
Intermittent sampling: User-set sample periods and sample delays. See Operating Instructions.
Flow Fault Features
If the pump is unable to compensate due to excessive back pressure, the pump will go into flow fault mode. Flow fault features are enabled as the default setting. Flow fault may be disabled at the user’s option. See Operating Instructions.
Flow fault: Flow fault displays immediately. Pump shuts off after 5 seconds.
Fault restart: Pump attempts restart every 10 seconds up to five times.
Media Compatibility
BioStage viable cascade impactors, spore trap cassettes, microvacuum cassettes, and other samplers that require flows to 30 L/min
Housing
ABS plastic
Dimensions
9.3 x 8.4 x 3.5 in (23.6 x 21.3 x 8.9 cm)
Weight
4.8 lbs (2.2 kg)

Applications

 Maintains true constant flow

  • Can be calibrated with any primary standard calibrator for valid calibration
  • Does not require a special rotameter or hot-wire anemometer for calibration
  • Can be used with remote sampling wand and media that creates back pressure such as wall cavity samplers
