Hand-held Atomic Fluorescence Spectroscopy Mercury Vapor Analyzer

The Jerome® J505 Mercury Vapor Analyzer is a portable fluorescence spectroscopy analyzer, which allows the detection cell to be simpler, smaller, lighter weight and more durable than competing spectroscopy instruments. The highly efficient optical cell requires less flow to purge the system, allowing the J505 to run at a lower flow rate minimizing sample dilution as found in competing spectroscopy instruments.

  • Meets EPA & ATSDR Cleanup Levels
  • Flexible Data Handling
  • Choice of Two Independently Adjustable High Limit Alarms
  • Programmable Auto Sampling Mode
  • Choice of 3 Units of Measurement (nanograms, micrograms, milligrams)
  • Color Display with Easy to Use Menu System
  • Battery Operation for 10+ Hours | Battery Charges in 3 Hours or Less
  • A USB Keyboard can be used for Easy Entry of Locations (optional)
  • Integrated Data Logging Saves all Test Results (excludes search mode)

Specifications

Detection Range 0.05 µg/m3 to 500 µg/m3
Accuracy
  • ±15% at 0.3 µg/m3
  • ±10% at 1 µg/m3
  • ±10% at 25 µg/m3
  • ±10% at 100 µg/m3
Response Time
  • Standard Mode: 28 seconds
  • Quick Mode: 16 seconds
  • Search Mode: 8 seconds, then updates in 1 second intervals
Resolution
  • Standard Mode: 0.01 µg/m3 (10 ng/m3)
  • Quick Mode: 0.1µg/m3 (100 ng/m3)
  • Search Mode: 0.1µg/m3 (100 ng/m3)
Flow Rate 1 liter/minute
Result Units ng/m3, µg/m3, and mg/m3
Autosample Mode Available in intervals of 1, 2, 5, 10, 15, 20, 30, 45, 60 or 120 minutes
Integrated Data Storage Stores up to 10,000 test results and up to 100 test sites
Display 3.5″ (9 cm) color LCD
Battery Rechargeable NiMH
10+ hour life, charges in 3 hours or less
Power Requirements 12 VDC power adapter runs on 100-240 VAC, 0.8 A, 50-60 Hz
Fuse Auto-resetting fuse
Operating Environment 5°C to 45°C, non-condensing, non-explosive
Output USB A
Dimensions 12″ L x 6.2″ W x 8.4″ H
(30.5 cm L x 15.7 cm W x 21.3 cm H)
Weight 6.5 lbs, (3.0 kg)
Certifications UL 61010, CE

Applications

  • First Responders
  • Biomass
  • Industrial Hygiene
  • Paints and Coatings
